Indoor and outdoor fiber distribution boxes are used for fiber connection, distribution and protection. It is made of metal and can be wall or pole mounted for easy testing and retrofitting of lines.
Product features
1. The box is designed with splicing unit, wiring unit and panel;
2. Adapters optional: FC, SC, ST, LC，E2000;
3. Suitable for single fiber and ribbon and bundle optical cable;
4. No gap, easy to manage and operate;
5. Cold-rolled steel electrostatic spraying, color RAL7035.
| Product Type | Max.Fiber Capacity | Size | Panel | Material Thickness |
| OTB-M018 | 12-24 F. | 75(0)x315 (H)x322(W) | 24×1 | EG 0.9 mm. |
| 48-60 F. | 138 (D) x 364 (H)x400 (W) | 60×1 | EG 1.2 mm. | |
| 96-120 F. | 156(D)x477(H)x410 (W) | 120 x 1 | EG 1.2 mm. | |
| 144 F. | 207 (D) x 635 (H )x410 (W) | 144 x 1 | EG 1.2 mm. | |
| 216 F. | 264 (D) x 850 (H)x430 (W) | 108×2 | EG 1.2 mm. | |
| 64 F. | 264 (D) x 850 (H)x430 (W) | 132×2 | EG 1.2 mm. |
Tolerance + 3.0mm
